——When parameters break through the limits, how to conquer hard rock and deep wells?

Get Free Quote

The evolution of core parameters

The golden combination of torque and speed

Hard rock layer: 40kN·m torque + 20-50rpm low speed (granite penetration rate ≥4m/h)

Gravel layer: 15kN·m torque + 80-120rpm medium speed (pebble layer anti-stuck drilling efficiency increased by 60%)

The revolution of the power system

Diesel-electric hybrid: fuel consumption reduced by 30% (Caterpillar C18 + permanent magnet motor)

Highland supercharging technology: power retention rate > 90% under working conditions at an altitude of 5000m

Intelligent leap

Automatic correction system: laser gyroscope accuracy ±0.1°/10m (compared to traditional ±0.5°)

Lithology AI identification: predicting the formation through drilling pressure/speed data (accuracy 85%)

Extreme environment case

Case 1: Challenge of geothermal wells on the Qinghai-Tibet Plateau

Working conditions: altitude 4800m + Basalt (compressive strength 250MPa)

Equipment: Schramm TXD90 drilling rig (diesel-electric hybrid, maximum torque 50kN·m)

Technical solution:

Diamond impregnated drill bit (carcass hardness HRC45)

Nitrogen foam circulation system (anti-freezing and plugging)

Results: Well completion depth 1200m, water temperature 112℃, setting a plateau record

Case 2: Emergency water supply in the Sahara Desert

Requirement: 200m well completion in 72 hours (sand layer has strong fluidity)

Equipment: Bauer BG 28 (equipped with air down-the-hole hammer)

Parameter configuration:

Air compressor displacement 24m³/min (sand discharge efficiency increased by 3 times)

Casing synchronous follow-up technology (anti-collapse hole)

Results: Single well water output 80m³/day, saving 3 nomadic villages
